12” Super Flexible RF Jumper Cable
High flexibility and low attenuation
Made of a high-quality copper conductor
12” Super Flexible RF Jumper Cable Description
The 1/2" Super Flexible RF Jumper Cable is a high-quality coaxial cable widely used in radio frequency transmission applications. It is designed to transfer signals with minimal signal loss, ensuring the best signal quality delivery between radio frequency transmitters and receivers.
This jumper cable has a robust construction, made up of a solid outer conductor, a dielectric insulation layer, a braided shield layer, and a central conductor. The solid outer conductor is made of copper or aluminum, which provides excellent shielding from electromagnetic interference and radiation. The dielectric insulation layer is made of foam or solid polyethylene, which provides low-loss and superior signal quality transfer.
The braided shield layer is made of copper wires that provide additional shielding capability and further minimize signal loss. The central conductor is typically made of copper or copper-coated steel, a low resistance conductor that enables superior conductivity and facilitates signal transfer.
Specifications
Insertion Loss:
Frequency | 1m | 2m | 3m | 5m |
890-960MHz | ≤0.15dB | ≤0.26dB | ≤0.36dB | ≤0.54dB |
1710-1880MHz | ≤0.20dB | ≤0.36dB | ≤0.52dB | ≤0.80dB |
1920-2200MHz | ≤0.26dB | ≤0.42dB | ≤0.58dB | ≤0.92dB |
2500-2690MHz | ≤0.30dB | ≤0.50dB | ≤0.70dB | ≤1.02dB |
5800-5900MHz | ≤0.32dB | ≤0.64dB | ≤0.96dB | ≤1.6dB |
Product Dimension
FAQ
